Hi,

This is CADian.

We have prepared 400+ Lisp programs to aid your CAD experience, free of charge!

Full List of all CADian Lisps : [Full CADian Lisp List]

How to Install : [CADian Lisps Download & Install Guide]

====================================================

1/ Command :

• OFDT

2/ Description : This tool automatically draws an Off-Delay Timer A-Contact symbol (Normally Open with Off-Delay) on a line, commonly used in electrical sequence drawings.

• Sequence Context: This tool is part of the electrical symbol series and requires you to　select a point along the line to determine the direction.

• Symbol Scaling: On the first run, you set the　insertion scale (e.g., input 1 for a 3mm circle diameter). You can adjust this later using the FAC command.

3/ How to Use :

1. Type OFDT in the command line and press Enter.

2. (First Run Only) Enter the Symbol　Insertion Scale (e.g., 1 for 3mm).

3. Select the Line where the symbol will be　inserted.

4. Click a point along the line to define the Direction (Up/Down or Left/Right).

5. The Off-Delay Timer A-Contact symbol is automatically drawn at the　selected location.
