1/ Command :

• WBOLT

2/ Description :
This tool automatically draws a wrench bolt based on standard specifications.

• Automation: Generates the complete side view of a wrench bolt including the head and threaded shaft.

• Standards: Supports standard wrench bolt sizes: 1.6, 2, 2.5, 3, 4, 6, 8, 10, 12, 14, 16, 20, 24, 30, 36, and 42.

3/ How to Use :

1. Type wbolt in the command line and press Enter.

2. Enter the Bolt Specification (Size) as a number (e.g., 10) and press Enter.

3. Click the Start Point.

4. Click the Second Point (Direction).

5. Enter the Total Length.

6. Enter the Effective Thread Length.
